We read your photo as:
List the standard metal shapes shown in the image, categorized by type.
Business/Management
ScanSolve AI Answer
Here are the standard metal shapes shown in the image:
SHEET AND PLATE
- Plate more than
- Sheet less than
- Diamond tread
- Standard expanded
- Flattened expanded
- Perforated sheet
STRUCTURAL SHAPES
- Angles
- Tees
- Channels
- Standard beams
- H-beams
- Wide flange
PIPE
- Standard schedule 40
- Extra strong schedule 80
- Double extra strong schedule 160
TUBING
- Round
- Square
- Rectangular
BAR STOCK
- Round
- Square
- Flat
- Half-round
- Half-oval
- Zee bar
- Hexagon
- Octagon
REINFORCING BAR
- Reinforcing bar
