What are the answers to the following technical drawing questions: 1. Which is NOT a type of scale? A. Micro scale B. Diagonal scale C. Vernier scale D. Plain scale 2. Which tool is NOT essential for

here are the answers to the questions:

WEEK 1 TUESDAY

1. Micro scale is not a recognized type of scale in technical drawing, unlike Diagonal, Vernier, and Plain scales.

   • A. Micro scale

2. While all listed tools are used in technical drawing, a protractor is primarily used for measuring and drawing specific angles. A compass, ruler, and set-square are more directly involved in drawing the lines and arcs that form the polygon's structure. For basic polygon construction, a compass and ruler are often considered fundamental, and a set-square helps with common angles. A protractor is for arbitrary angles.

   • D. Protractor
