You're on a roll — TASK: Draw a wiring diagram for the bell circuit shown in Figure 2. This is a schematic wiring diagram based on the provided description and layout for the bell circuit. Power Supply: A 240V AC supply (Live, L, and Neutral, N) serves as the main power source. The primary winding of the Transformer (T/X) is connected across the 240V Live (L) and Neutral (N) lines. The secondary winding of the Transformer (T/X) provides a 12V AC supply. Let's designate these lines as 12V Live (L') and 12V
