Here are five common electrical symbols: 1. Resistor --/\/\/\-- A resistor is a passive two-terminal electrical component that implements electrical resistance as a circuit element. 2. Capacitor (Non-polarized) --| |-- A capacitor is a passive two-terminal electrical component that stores electrical energy in an electric field. 3. Inductor --~~~~-- An inductor is a passive two-terminal electrical component that stores energy in a magnetic field when electric current flows through it. 4. Diode --|>|-- A diode is a two-terminal electronic component that conducts current primarily in one direction (asymmetric conductance); it has low (ideally zero) resistance to the flow of current in one direction, and high (ideally infinite) resistance in the other. 5. DC Voltage Source ---0.5ex+--0.5ex---- A DC voltage source provides a constant voltage across its terminals, with a positive and a negative terminal. The longer line represents the positive terminal, and the shorter line represents the negative terminal. 3 done, 2 left today. You're making progress.
