We read your photo as:

In a circle with centre O, the central angle SOP and inscribe angles SRP and STP are standing on same arc SP. a) Write the relationship between central angle and inscribe angle standing on the same ar

Mathematics

ScanSolve AI Answer

Answers

2 parts
a

केन्द्रीय कोण=2×परिधि कोण\text{केन्द्रीय कोण} = 2 \times \text{परिधि कोण}

b

x=20x = 20

Step-by-step solution

3 steps

यहाँ समस्या 2 को समाधानहरू छन्:

2. In a circle with centre O, the central angle SOP and inscribe angles SRP and STP are standing on same arc SP.

Part a

Write the relationship between central angle and inscribe angle standing on the same arc.

एउटै चापमा आधारित केन्द्रीय कोण परिधि कोणको दोब्बर हुन्छ।
अर्थात्, केन्द्रीय कोण=2×परिधि कोण\boxed{\text{केन्द्रीय कोण} = 2 \times \text{परिधि कोण}}.
यस अवस्थामा, ∠SOP=2×∠SRP\angle SOP = 2 \times \angle SRP र ∠SOP=2×∠STP\angle SOP = 2 \times \angle STP.

Part b

x=20x = 20

The measurement of the central angle is (x+60)∘(x + 60)^\circ and the measurement of the inscribe angle is (2x)∘(2x)^\circ. Find the value of xx.

  1. केन्द्रीय कोण र परिधि कोण बीचको सम्बन्ध प्रयोग गर्नुहोस्।

    हामीलाई थाहा छ कि केन्द्रीय कोण परिधि कोणको दोब्बर हुन्छ।

    केन्द्रीय कोण=2×परिधि कोण\text{केन्द्रीय कोण} = 2 \times \text{परिधि कोण} (x+60)∘=2×(2x)∘(x + 60)^\circ = 2 \times (2x)^\circ
  2. समीकरणलाई सरल गर्नुहोस्।

    x+60=4xx + 60 = 4x
  3. xx को लागि हल गर्नुहोस्।

    60=4x−x60 = 4x - x 60=3x60 = 3x x=603x = \frac{60}{3} x=20x = 20

    The final answer is x=20\boxed{x = 20}.

Part c

Verify experimentally that the inscribed angles STP and SRP are equal. (Two different circles with radii of at least 3 cm are required.)

प्रयोगात्मक रूपमा पुष्टि गर्न, तपाईंले निम्न चरणहरू पालना गर्नुपर्छ:

  1. कम्तिमा 3 से.मी. अर्धव्यास भएका दुई फरक वृत्तहरू बनाउनुहोस्।
  2. प्रत्येक वृत्तमा, केन्द्र O र चाप SP कोर्नुहोस्।
  3. चाप SP मा आधारित परिधि कोणहरू ∠STP\angle STP र ∠SRP\angle SRP बनाउनुहोस्।
  4. प्रोटेक्टर प्रयोग गरेर ∠STP\angle STP र ∠SRP\angle SRP को नाप लिनुहोस्।
  5. तपाईंले दुवै कोणको नाप बराबर भएको पाउनुहुनेछ।

सैद्धान्तिक रूपमा, एउटै चापमा आधारित परिधि कोणहरू बराबर हुन्छन्। यसकारण, ∠STP\angle STP र ∠SRP\angle SRP दुवै चाप SP मा आधारित भएकाले, तिनीहरू बराबर हुनुपर्छ।

Was this helpful?

Try one yourself

A new problem that tests the same skill.

Still stuck on this one?

Ask a follow-up, and the answer starts from this question.

Got a different question?Ask your own question
Handwritten step-by-step solution preview
