We read your photo as:
The nameplate of an Ingersoll-Rand 3-M Type 112 M4 motor shows the following specifications: Nr. 28499, 55 kW, 400 V, 84 A (50Hz), 50 Hz, IP 55, Cos φ 0.84, 1428 min-1. Calculate the power factor and the full load current in Amperes.
Physics
ScanSolve AI Answer
Here are the key specifications from the motor nameplate:
- Manufacturer: INGERSOLL-RAND
- Type: 3-M TYPE 112 M4
- Rated Power: 55 kW
- Rated Voltage: 400 V (Delta connection) / 690 V (Star connection)
- Rated Current: 81 A (at 400 V) / 47 A (at 690 V)
- Frequency: 50 Hz
- Power Factor (): 0.84
- Rated Speed: 1428 min⁻¹ (RPM)
- IP Protection Class: IP 55
- Insulation Class: F
