If sigma 1, sigma 2 and sigma 3 are the conductances of three conductors, then their equivalent conductance. When they are joined in series will be:

Physics

ScanSolve AI Answer

Step-by-step solution

4 steps
  1. प्रतिरोध (RR) और चालकता (σ\sigma) के बीच संबंध स्थापित करें।

    चालकता प्रतिरोध का व्युत्क्रम होती है।

    σ=1R\sigma = \frac{1}{R}

    इसलिए, R=1σR = \frac{1}{\sigma}।

  2. श्रेणी क्रम में जुड़े चालकों के लिए समतुल्य प्रतिरोध का सूत्र लिखें।

    जब तीन चालक श्रेणी क्रम में जुड़े होते हैं, तो उनका समतुल्य प्रतिरोध (ReqR_{eq}) उनके व्यक्तिगत प्रतिरोधों का योग होता है:

    Req=R1+R2+R3R_{eq} = R_1 + R_2 + R_3
  3. समतुल्य प्रतिरोध के सूत्र को चालकता के पदों में परिवर्तित करें।

    R=1σR = \frac{1}{\sigma} संबंध का उपयोग करके, हम लिख सकते हैं:

    1σeq=1σ1+1σ2+1σ3\frac{1}{\sigma_{eq}} = \frac{1}{\sigma_1} + \frac{1}{\sigma_2} + \frac{1}{\sigma_3}

    दाहिनी ओर के भिन्नों को जोड़ें:

    1σeq=σ2σ3+σ1σ3+σ1σ2σ1σ2σ3\frac{1}{\sigma_{eq}} = \frac{\sigma_2 \sigma_3 + \sigma_1 \sigma_3 + \sigma_1 \sigma_2}{\sigma_1 \sigma_2 \sigma_3}
  4. समतुल्य चालकता (σeq\sigma_{eq}) के लिए हल करें।

    समीकरण को व्युत्क्रम करने पर, हमें समतुल्य चालकता मिलती है:

    σeq=σ1σ2σ3σ1σ2+σ2σ3+σ1σ3\sigma_{eq} = \frac{\sigma_1 \sigma_2 \sigma_3}{\sigma_1 \sigma_2 + \sigma_2 \sigma_3 + \sigma_1 \sigma_3}

    यह विकल्प D से मेल खाता है।

    The final answer is D) σ1σ2σ3σ1σ2+σ2σ3+σ1σ3\boxed{\text{D) } \frac{\sigma_1 \sigma_2 \sigma_3}{\sigma_1 \sigma_2 + \sigma_2 \sigma_3 + \sigma_1 \sigma_3}}.

Was this helpful?

Still stuck on this one?

Ask a follow-up, and the answer starts from this question.

Got a different question?Ask your own question
Handwritten step-by-step solution preview
